Tesa® ACXplus 7074 HIGH RESISTANCE VHB Acrylic Foam Tape
Applications The tesa® ACXplus product family is suitable for a wide range of constructive bonding
Read More| Dimension | Action |
|---|---|
| 1/4" x25m | |
| 1/2" x25m | |
| 3/4" x 25m | |
| 1" x 25m | |
| 1.5" x 25m | |
| 2" x 25m |
- Category:Double-Sided Tapes
- Sub Category:VHB Acrylic Foam Tapes
Product description
tesa® ACXplus 7074 is a deep black double-sided acrylic foam tape. It consists of a high-performance acrylic system and is identified by its bonding power, stress dissipation, and its temperature and weather resistance. Due to the product's unique formulation, this double-sided pure acrylic foam tape combines a very good temperature and shear resistance with an outstanding cold shock resistance up to - 40º. This product also shows robustness when it comes to outdoor performance. The viscoelastic core of this product is able to compensate for thermal elongations of bonded parts. tesa® ACXplus 7074 is especially designed for permanent demanding outdoor bonding applications and is therefore suitable for exposure to extreme temperatures, UV, chemicals, salt water, as well as cleaning agents.
| Material | Foamed acrylic |
|---|---|
| Colour | Deep Black |
| Brand | Tesa |
Technical Information
Any custom width can be slit. Please contact our sales team to discuss your unique width requirements.
| Elongation at break | 1000% |
|---|---|
| Type of adhesive | Pure Acrylic |
| Tensile strength | |
| Total Thickness | 1000 μm |
| Backing material | foamed acrylic |
| Color | deep black |
Please note that we recommend using tesa® Adhesion Promoter as a surface pre-treatment. It leads to a significant improvement in adhesion levels, avoids moisture infiltration, and promotes long-term resistance against harsh environmental factors. Which tesa® Adhesion Promoter should be used depends on the substrates and the application. We will be glad to advise you in order to find the right solution. Liner versions: PV22: White paper liner - branded, PV24: Blue film liner - unbranded, Further liner versions might be available upon request. Certificates: tesa® ACXplus 7074 is recognized according to UL Standard 746C. UL File QOQW2.E309290 tesa® ACXplus 7074 is recognized according to UL Standard 879. UL File UYMR2.E479260 Rosenheim: Certified in accordance with EN 1435-1:2006+A1:2010 - Air permeability, water tightness, Resistance to wind MPA Stuttgart: Dynamic tensile measurement according to ETAG002 following EN 28339 ATI: ASTM E 283-04, 330-02, 331-00 wind load and water penetration test Qualified for credit according to LEED
